ChipProg Device Programmers
ACI_Launch
ACI_FUNC ACI_Launch(ACI_Launch_Params * params);
Description
This function launches the ChipProgUSB software. Optionally this ACI function can launch the
programmer with a specified command line key and load the file that will configure the ChipProg
hardware.
This ACI function must always be called before any other ACI function !
ACI_Exit
ACI_FUNC ACI_Exit();
Description
Call of this function stops the ChipProgUSB software. In most cases the programmer practically
immediately stops running. Sometimes, after calling the ACI_Exit function, it continues working for a
while to correctly complete an earlier launched process. After all the ChipProg will stop and quite itself
after finding that the controlling process has ended.
It is possible, however, that the software will keep running even after the control process has completely
stopped. This is abnormal situation and, as the result, it will be impossible to re-establish
communication with the programmer hardware by launching the ACI_Launch function. In this case you
should manually close the ChipProgUSB program via the Window Task Manager.
.
ACI_LoadConfigFile
ACI_FUNC ACI_LoadConfigFile(ACI_Config_Params * params);
Description
This function loads the ChipProg configuration parameters that include all the settings available via the
ChipProgUSB dialogs (memory buffer configurations, programming options, test of the device insertion,
etc.).
The ChipProgUSB program automatically saves some programming options and settings including a
type of the selected device, the device parameters, the start and end addresses of the device being
programmed, the buffer start address, and a set of the AutoProgramming commands and then
automatically restores these parameters when the user changes the device type.
See also: ACI_SetProgrammingParams , , ACI_GetProgrammingParams , ACI_GetProgOption ,
ACI_SaveConfigFile
? 2010 Phyton, Inc. Microsystems and Development Tools
